TESE is a precision hot air station capable of reworking small and medium SMDs.
The combination of the exclusive JBC hot air system with protectors, tripods and extractors ensures desoldering components easily and safety, concentrating the heat on the selected component as show:
Desoldering with TESE Precision Hot Air Station
1. Placing
Choose the extractor, or protector and tripod, which best fits the component.
2. Heating
While you apply the heat to the component, the surrounding elements are protected
3. Extracting
Automatic withdrawal of the desoldered component.
Connecting an
external thermocouple provides a high-precise close-loop control of the component/PCB during the rework process or can also be used to protect a component or a specific area of the PCB.
As all the JBC Stations, the TESE has a menu with more than 10 parameters to customise the control unit.
PRODUCT COMPOSITION
SPECIFICATIONS
Selectable Temperature
150 to 450 ºC (300-840 ºF)
Vacuum
30% / 228 mmHg / 9 inHg
Profiles
25 (up to 10 steps for each), 1 preset profile
Type K TC connector
1 for Control & Protection
ESD safe
Meet ANSI / ESD S20.20-2021
Equipotential bonding
Connection to EPA
Pedal connector
Tool control
Control Unit
232 x 148 x 160 mm / 4.72 kg.
