The TESE-Q is a precision hot air Station capable of reworking small and medium SMDs. Watch video for examples.
Connecting an external thermocouple provides a high-precise close-loop control of the component/PCB during the rework process or can also be used to protect a component or a specific area of the PCB.
As all the JBC Stations, the TESE-Q has a menu with more than 10 parameters to customise the control unit.
PRODUCT COMPOSITION
1 Hot Air Control Unit
1 TET Precision Heater Hose Set
1 TN9209 Straight Nozzle Ø3 for TET
1 TN9208 Straight Nozzle Ø4 for TET
1 TN9080 Straight Nozzle Ø5 for TET
1 TES Stand for TE Precision Heater Hose Set
1 PH218 Thermocouple Type K
SPECIFICATIONS
Selectable Temperature
150 to 450 ºC (300-840 ºF)
Air flow
2 to 17 SLPM
Temperature profiles:
Design specific thermal profiles to avoid thermal shock during soldering processes.
Up to 25 fully configurable soldering profiles can be stored.
Operating modes
Heating / Profiles / Cooling
Vacuum
30% / 228 mmHg / 9 inHg
CONNECTIVITY
Type K thermocouple:
Can be used both for Control and Protection purposes.
USB-B (rear)
Software PC
USB-A (front)
Firmware update, Graphics / Profiles management
Robot
RS-232 remote control
Pedal
Optional tool control
Equipotential bonding
Optional connection to EPA
ESD/EOS
ESD safe
POWER SUPPLY
Nominal power
300 W
Operating temp. range
10 to 50 ºC / 50 to 120 ºF
DIMENSIONS AND WEIGHT
Premium Stations
230 x 148 x 160 mm / 3.44 kg
