Accuracy is the right word!
Ideal for soldering SMD.
It provides all the advantages of the JBC Most Efficient Soldering System in the smallest footprint:
JBC Intelligent Heat Management provides the best soldering quality and with, Sleep & Hibernation Modes extend tip life till 5 times.
Complete Tip Cleaning System, with exclusive fast and safe Cartridge Exchanger.
Connectivity:
- Fume Extractor
- Data Download
- Software Updates
- Traceability
Includes T210 Precision Handle that works with our wide range of C210 Cartridges.
SPECIFICATIONS
Peak power (Tool)
Selectable temperature
90 to 450 ºC / 190 to 840 ºF
Idle temp. stability (still air)
±1.5 ºC - ±3 ºF (Meets and exceeds IPC J-STD-001)
Temperature accuracy
±3 % (Using reference cartridge)
Temp. adjustment
±50 ºC / ±90 ºF (Through station menu setting)
Tip-to-ground resistance
<2 ohms
Tip-to-ground voltage
<2 mV RMS
FAE / Robot connector
Remote control or FAE Fume Extractor connection
ESD safe
Meet ANSI/ESD S20.20-2021
Control Unit
170 x 176 x 145 mm / 2.70 kg.
