B·IRON DUAL 500 is specially designed for continuous work in mass production.
It performs up to 500 medium-sized SMD soldering joints per charge.
This station converts into a dual-tool station by adding an extra tool. Both tools can be controlled in real time.
Included:
• B·500 Handle (x2), which is fully compatible with C210 Cartridge Range. It also has a power safe mode that can be activated by putting on the cap.
• Charging-Base for charging booth tools automatically when placed in Tool Holder.
It also features Quick Cartridge Exchanger, enabling a safe and easy cartridge change, Tip Cleaner with Brass Wool and Antisplash Membrane.
• PDS Portable Display 7" with B·IRON app to configure and control the system.
* Also available without display, as you can use your own device. Contact us for more information.
PRODUCT COMPOSITION
|
CHARGING BASE
Input voltage
100 V - 240 V 50/60 Hz
Power
40 W
Tool output
12 V / 1000 mA
USB output
5 V / 1000 mA
|
TOOL
Output peak power
24 W
Battery
Li-Ion 7.4V / 750 mAh
Charge time
60 minutes
Selectable temperature
100 to 450ºC / 210 to 840ºF
Idle temp. stability (still air)
±1.5 °C / ±3 °F
Temperature accuracy
± 3% (Using reference cartridge)
Connections
Bluetooth Low Energy (BLE)
Ambient Operating Temp
10 - 50 °C / 50 - 122 °F
Tool Weight
70 g / 0.154 lb
|
|
Weight and dimensions
B·IRON System
233 x 202 x 211 mm / 2.13 kg.
9.17 x 7.95 x 8.31 in / 4.70 lb.
Package
265 x 223 x 160 mm / 2.74 kg.
10.43 x 8.78 x 6.30 in / 6.05 lb.
|
